Electron Sharing Reactions

Have you ever wondered why oxygen exists as O₂ in the air, or why water sticks together? The answer to those questions is in the way the atoms share electrons. The sharing of electrons is the most common way to create a chemical bond, and these reactions explain the stability of just about every molecule in the world around us.

What is an Electron Sharing Reaction?

An electron sharing reaction is a chemical reaction in which two or more atoms share electrons, in order to achieve a stable electron configuration. In contrast to ionic reactions, in which identical or different atomic species lose or gain electrons, in an electron sharing reaction a covalent bond is formed, and the atoms in the bond 'capture' and hold the electrons being shared.

  • Involved atoms: Usually the nonmetals like hydrogen, oxygen, nitrogen, and carbon.
  • Goal: Completing of the outermost electron shell (most atoms obey the octet rule, hydrogen follows the duet rule).
  • Result: Formation of stable chemical bonds, and the molecules are in a stable state.

When two hydrogen atoms come together, they each share one of their electrons, and they both get to fill up their outer shells, bonding together to create H₂.

Covalent Bonding

The most frequent result of chemical reactions involving electron sharing are covalent bonds.

Single Covalent Bond

One pair of electrons shared between two bonded atoms

Example: H–H (hydrogen)

Double Covalent Bond

Two pairs of electrons shared between two atoms

Example: O=O (oxygen)

Triple Covalent Bond

Three pairs of electrons shared between two atoms

Example: N≡N (nitrogen)

Covalent Bonds Basics:

  • Electrons are shared between both atomic nuclei, which is what keeps the two atoms bonded.
  • Atoms are in a more stable state and lower energy level, which is what drives the formation of a covalent bond.
  • Atoms can bond as many times as the number of electrons in the outermost shell (valence shell) which the atom needs to complete the shell.

Structure of Molecules

The form and the structure of the molecules are the result of the reactions of shared electrons. The predicted shape is based on VSEPR Theory (Valence Shell Electron Pair Repulsion):

Electron pairs push each other and are neutral to the surrounding molecules. This repulsion drives the molecule to orient in a way that electron pairs are as separate as possible.

Common Shapes:

Linear
e.g., CO₂
Bent
e.g., H₂O
Trigonal Planar
e.g., BF₃
Tetrahedral
e.g., CH₄
  • Shape can influence both the physical and chemical nature of the molecule.
  • Lone pairs of electrons can distort bond angles.
  • Structures of molecules determine the bond polarity and molecular polarity.

Bond Polarity and Molecular Polarity

Sharing of electrons is not always an equal activity. At times, one of the atoms will capture the shared electrons with more force than the other.

Electronegativity is the strength of an atom to pull the shared electrons towards itself.

  • When there is an unequal sharing of electrons in a covalent bond, partial charges are induced. For example, the covalent bond of hydrogen and chlorine is a polarized bond.
  • In a non-polar covalent bond, there is equal sharing of electrons. For example, the covalent bond of 2 hydrogen atoms.

The shape of a molecule and polarity of the bonds will determine the polarity of the molecule.

  • Symmetric arrangements of polar bonds in a molecule results in a non-polar molecule.
  • In an asymmetric arrangement of the polar bonds, the molecule is polar and will interact with other molecules in a unique way.

Factors Affecting Electron Sharing Reactions

Several factors influence the stability of a bond:

  • Electronegativity difference: Large difference → ionic; small difference → covalent.
  • Size of atom: Smaller atoms bind covalently more strongly because shared electrons are closer to nuclei.
  • Number of valence electrons: Determines the number of bonds an atom can form.
  • Octet completion: Atoms share electrons until the outer shell is filled.

Bond Strength and Bond Energy

A more stable, low energy state will result when atoms share electrons. Therefore, electron sharing reactions will always release energy.

Bond energy is defined as the amount of energy needed to break one mole of a given bond in a given molecule.

A bond is considered stronger the more energy is required to break it. Therefore, triple bonds have a higher bond energy than single bonds.

The energy changes that occur in chemical reactions when electrons are shared accounts for the reason some chemical reactions are said to be exothermic (give off energy) or endothermic (take in energy).

Multiple Bonds

In some instances, in order to satisfy the octet rule, the involved atoms share several pairs of electrons:

  • Double bond: two shared pairs of electrons. Example: carbon dioxide (C=O).
  • Triple bond: three shared pairs of electrons. Example: nitrogen gas (N≡N).

A rule of thumb: multiple bonds are stronger and shorter than single bonds. Additionally, molecules that contain multiple bonds have restricted rotation compared to single bonded molecules, impacting geometry and reactivity.

Reactions with Resonance

Some molecules cannot be represented by a single Lewis structure as they are said to have multiple resonance structures. For such molecules, the arrangement of electrons can vary.

Example: O₃ (ozone)

  • The structure of ozone can be represented by more than one Lewis structure.
  • The resonance structures delocalize the electrons of the molecule, increasing stability.
  • Resonance structures are important for determining reactivity and bond length in aromatic compounds like benzene.

Coordinate (Dative) Covalent Bonds

In some chemical reactions involving electron sharing, both electrons in the shared pair come from one of the atoms:

NH₃ + H⁺ → NH₄⁺

In such a reaction, the nitrogen atom donates a lone pair to form a coordinate bond with the proton. Covalent bonds have a regular bond formation process.

Intermolecular Forces

The sharing of electrons also impacts intermolecular forces:

  • Dipole-dipole interactions: occur between polar molecules.
  • Hydrogen bonding: strongest intermolecular force, occurs when H is bonded to N, O, or F.
  • London dispersion forces: weakest, but significant for large nonpolar molecules.

Why Electron Sharing Reactions Are Important

Covalent bond formation (electron sharing) explains:

  • Molecular formation: structure and shape of molecules.
  • Physical properties: boiling/melting point, solubility, conductivity.
  • Chemical reactivity: interaction of molecules and formation of new substances.
  • Biological processes: DNA base pairing, protein structure, enzyme action.

Everyday Examples:

  • H₂O has a bent shape due to covalent bonds causing polarity.
  • O₂ is a double-bonded molecule, stable in the atmosphere.
  • CH₄ is tetrahedral, low boiling point, exists as a gas.

Summary

Important Points to Note

  • The formation of covalent bonds is a reaction of sharing electrons.
  • The type of bond (single, double, triple) decides length and strength.
  • The shape of a molecule determines its polarity and physical properties.
  • Electronegativity difference determines bond polarity.
  • Resonance and coordinate covalent bonds are special cases.
  • When bonds are made or broken, energy is either released or absorbed.
  • Electron distribution leads to intermolecular forces affecting physical properties.

The reaction of molecular bonds and the sharing of electrons is not an abstract idea; it shows the world around us at a molecular scale.
